NPT 1/4 Auto Air Pressure Sensor For Universal Diesel Trucks

Product Description

Air pressure sensor is high quality, high stability, small size. low weight. Compact structure, low cost and mass production. The products are widely used to measure of air compressors, auto engines, air conditioning equipment etc. The product is made of carbon steel , SS304 / 316 or brass, which is ideal for industrial environment.

Application

Automotive Engine

Automotive Brake System

Air Compressor

Agricultural Machinery Engine

Generator Engine

Diesel Engine

Hydraulic Control System

Technical Data

Operating voltage: 6~24V

Conducting power: < 5W

Operating temperature: -25 ~120℃ (120℃ MAX 1H)

Measuring range: 0~5 Bar or 0~10 Bar

Alarm: 0.8 Bar or 1.4 Bar

Output signal: Standard resistance value: 10~184Ω

Thread fitting: NPT1/4, NPT1/8, M10, M10x1 or customized as requires.

Protection rank: IP66

Feature

Superior long term stability

Temperature compensated over wide range

Low power consumption

Excellent repeat-ability / Hysteresis

Special design for customer

Many OEM options

Instruction

This product is matched with the pressure gauge and alarm, it senses the change of engine oil pressure (or brake system pressure), and transfers the amount of change to the pressure gauge for real-time display. When the pressure is lower than the set value, the low voltage switch is on and the alarm light is on. This product is simple in structure, convenient in use and reliable in performance.
